DS-2CE16D7T-IT – Turbo HD 3.0

DS-2CE16D7T-IT – Turbo HD 3.0

Mã: DS-2CE16D7T-IT
– Cảm biến CMOS, 2 Megapixel
– Đầu ra Analog HD, độ phân giải 1080P
– Ống kính: 2.8mm, 3.6mm, 6mm lens
– Tự chuyển chế độ ngày đêm
– Menu điều khiển OSD thông qua cáp đồng trục (HIKVISION-C)
– Chống nhiễu DNR
– Hồng ngoại thông minh EXIR 20m
– Chống ngược sáng thực (True WDR) 120dB
– Tiêu chuẩn ngoài trời IP66
Camera an ninh, DS-2CE16D7T-IT – Turbo HD 3.0
Bảo hành: 24 tháng

Camera
Image Sensor: | 2MP CMOS Image Sensor
Signal System: | PAL/NTSC
Effective Pixels: | 1928(H)*1088(V)
Min. Illumination: | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time: | 1/25(1/30) s to 1/50,000 s
Lens: | 2.8mm, 3.6mm, 6mm, optional @ F1.2
Angle of View: 103°(2.8mm), 82.2°(3.6mm), 54°(6mm)
Lens Mount: | M12
Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120dB
Video Frame Rate: | 1080p@25fps/1080p@30fps
HD Video Output: | 1 Analog HD output
Synchronization: | Internal Synchronization
S/N Ratio: | More than 62 dB
Up the Coax: | Support
Menu
Auto White Balance: | Auto/MWB
BLC: | Support
AGC: | Support
Language: | English/Chinese
Function: | Wide Dynamic Range; Digital Noise reduction; Mirror; SMART IR
General
Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: | 12 VDC±15%
Power Consumption: | Max. 5W
Weather Proof: | IP66
IR Range: | Up to 20m
Communication : | Up the coax
Protocol: HIKVISION-C(Coaxitron)
Dimension: | 58.5mm×55.5mm×153.6mm (2.30”×2.19”×6.05”)
Weight: | Approx. 370g (0.82lb)
